Ford F-150 Series pick-up trucks, E-150 Series vans, Expeditions, Explorers, Crown Victorias, Thunderbirds, and Mustangs.Lincoln Town Cars and Mark VIIIs.Mercury Grand Marquis, Cougars, Mountaineers and Marauders.
What years did Ford use the 4R70W transmission?
Ford’s AOD transmission begat the AODE, which then spawned the 4R70W. This transmission was used for 10 years: 1993 to 2003 in the F-150 pickup, 1997 to 2004 in the Expedition, 1996 to 2001 in the Explorer, along with the Mustang, Thunderbird, Cougar, Crown Victoria, and many more Ford applications.
How do I know if I have a 4R70W transmission?
Look for the electronic cable and electrical plug. AODE and 4R70W transmissions have a plug on the driver’s-side rear of the transmission housing. This is where the electronic control cable plugs into the unit and is what differentiates the older AOD transmission from AODE and 4R70W units.
Is the Ford 4R70W a good transmission?
The 4R70W is a good transmission, but it has its pros and cons. Let’s look over some of its best qualities, and some of its faults and issues. For one, it has a much better and improved overdrive band. … That, and as with any other transmission, you still need to maintain it regularly.What does a 4R70W fit?
4R70W usage in cars: 3.8 L V6 Ford Mustang. Ford Panther platform Cars: Ford Crown Victoria, Mercury Grand Marquis, Mercury Marauder and Lincoln Town Car.
How do I identify a Ford AODE transmission?
The AOD transmission can be identified in several ways. Its prominent 14-bolt pan is probably the easiest way. The pan is basically square but the back two corners are tucked in a little tighter than the front corners making the pan look like home plate with the front point cut off.
Is the 4R70W transmission electronic?
The AODE and 4R70W transmissions were an all-new AOD case designed for electronic interaction with engine controls. The AODE and 4R70W are essentially the same AOD-based transmission.
How many quarts does a 4R70W transmission take?
The 4R70W holds 12-13 quarts of ATF fluid, do not over-fill the transmission.Will a 4R70W fit a 302?
Loc. – A 4R70W or AODE from behind any 5.0 (302) or V6 3.8L Mustang or V6 4.2L F150 will bolt up/work behind any 289/302/5.0/351W/351C/5.8L.
How much does a 4R70W transmission weight?Transmission around 135lbs. When I ship them on a pallet, I usually call them about 220lbs.
Article first time published onCan I replace a 4R70W with a 4R75W?
For the tranny, the 4r75w and 4r75e are pretty much identical, but the 4R75E is just newer. The 4r75 cases are the same as the 4r70, so it will bolt directly in with the same dimensions and everything, and the driveshaft will remain the same.
Are all 4R75E transmissions the same?
Functionally, the 4R75E and 4R75W are the same. The letter on the end of the transmission specification changed depending on the vehicle the transmission was put in; however, both the 4R75E and 4R75W will do the job well.
How can I tell what transmission I have?
White Card on Driver’s Door Open the driver’s side door and find the white card on the side of the door that is filled with small black lettering. This card contains specific details about the year the car was made, its transmission, engine specifications and other details.
Is the 4R70W computer controlled?
In 1993, Ford upgraded the AODE and gave it a new name: the 4R70W. It was very similar to the AODE with improvements such as the use of lighter materials, as well as a new-and-improved valve body with computer-controlled solenoid packages.
What is the difference between AOD and 4R70W transmission?
The AODE has a thicker, simpler, and much more reliable valve body that is much less likely to warp than the thinner more complex AOD valve body. … Beginning in 1998, the 4R70W also has the Mechanical Diode intermediate one way clutch, and an even better direct input shaft.
What years did Ford use the AODE transmission?
Ford AOD, AODE Automatic Transmission The AOD was introduced for the 1980 model year and used in the 1980 to 1986 F-150, 1982 to 1993 Ford Bronco, and many Ford passenger cars. It was Ford’s first 4 speed overdrive transmission and was used to replace many of their 3 speed transmissions (C4, C5, etc).
What is an AODE W transmission?
The AODE is truly a state-of-the-art automatic transmission, with its pressure controlled internally, not coming from a TV cable as in the AOD. It’s also much stronger from the start, able to hold 200 more horses in factory trim. And it has better internal components, including all gear material and hardware.
How strong is a Ford AOD transmission?
The bulletproof nature of the Ford AOD transmission can be unraveled just by knowing the right buttons to push. When that has been put in place, you can boost its performance from about 400 hp to as high as 1,200 hp which makes for excellent speed while racing.
What transmission does a 2004 f150 have?
Transmission:Ford 4R75W & 4R75EType:4 speed overdrive automatic transmissionPredecessor:Ford 4R70WApplications:2003 – 2008 Ford F-Series, 5.4L V-8 exclusively for 2004 and 2005 model yearsCase Material:Aluminum
What vehicles have a 4R100 transmission?
The Ford 4R100 transmission is an updated version of the E4OD and was first introduced in the 1999 model year, and is currently found in the F250, F350, F450 and F550 Super Duty trucks, E150, E250, E350, E450 vans and the Expedition/Navigator/Excursion vehicles equipped with the 5.4L, 6.8L, and 7.3L engines.
Will a 5.0 bolt up to a 4R70W?
As far as fitting a trans goes, the 4R70W that runs behind the 4.6 will not bolt up to a 5.0 because it has a different bellhousing bolt battern. You’ll need a trans from another 5.0 car, or a 3.8 V6 car.
What is the difference between Mercon V and Mercon LV?
Mercon V is the most common automatic transmission fluid for a ford model. … On the other hand, Mercon LV is not compatible with any Mercon fluids. Even it doesn’t be mixed with Mercon V. Since Mercon LV is designed to meet the demands of most modern transmissions, it is compatible with older GM Dexron specifications.
How do you fill a 4R70W transmission?
Torque the transmission pan bolts to 108 – 132 in-lbs (inch pounds!) in a criss cross pattern for the 4R70W and 4R75W. Refill the transmission with new ATF through the transmission dipstick located on the passenger side of the engine bay. Fill until fluid level reads full on the dipstick indicator.
What is Mercon V?
Motorcraft® MERCON® V is a premium-quality automatic transmission fluid recommended by Ford Motor Company for use in Ford, Lincoln and Mercury vehicles that require either MERCON® V or MERCON® type fluid. This product also provides excellent performance in electronically controlled automatic transmissions.
How much does a Ford transmission weigh?
The weight of a Ford F-150 transmission will be approximately 215 lbs. This is a fairly light weight transmission as sometimes they can reach approximately 400 lbs. The transmission weight will be determined on how it is designed and functions that will cause it to be transmitting power from the engine to the wheels.
How do I know if I have 4R70W or 4R75W?
More. If you look on the other side of the transmission at the speed sensor, you’ll find that the AOD and 4R70W have a single sensor near the tail of the transmission. The 4R75W has two-speed sensors, one by the tail and one towards the center.
What vehicles have a 4R75E transmission?
- Ford (F-150 Series pick-up trucks, E-150 Series vans, Explorers, Expeditions, Crown Victorias, Mustangs and Thunderbirds)
- Lincoln (Town Cars and Mark VIIIs)
- Mercury (Cougars, Grand Marquis, Mountaineers and Marauders)
How many gears does a 2004 f150 have?
DrivetrainDrive typeRear wheel driveRear limited slip differentialyesTransmission4-speed automatic
What kind of transmission is in a 2005 Ford f150?
Year2005Transmission Tag7L3P-AA, 6L3P-AB, 5L3P-AA, 6L3Z-ARM, 6L3P-AA, 5L3Z-ARMTransmission Code4R75ETransmission Speed4Transmission Drive TypeRWD
Does VIN number tell your transmission?
For many makes, the VIN is always enough information to determine transmission.
